Female Fanout Fibre Optic Ethernet Cable 4 Duplex LC 40 Gigabit
This is kind of Cable often used interchangeably, with the
difference being MTP connectors featuring higher performance and
enhancements (MTP "Multi-fiber Termination Push-on" is a connector
made by USConec that is fully compliant with MPO standards
(Multi-fiber Push-on), while offering increased performance and
features), MPO or MTP connectors are a multi-fiber solution,
offering a higher port density compared to traditional fiber
options. The use of MPO / MTP fiber solutions utilizes one cable to
hold 12 fibers, making it easy to plug-in and perfect for use in
compact server rooms or when simplifying installation is a
necessity.
MTP / MPO cables can be used with cassettes or connections to
active equipment with MPO / MTP interfaces. The ability to hold
multiple fibers, coupled by its simplified connect and reconnect
mechanism (push-pull) allows easier installation, increased
efficiency, and cost benefits compared to running individual fiber
cables.
40Gbase-SR4 OM3 3mm OFNP 3 Meter with Flex Boot
What is QSFP+ 40GBase-SR4?
SR4 - short range, Multimode (850nm, or 50/125nm)
MTP/MPO Connector
OM3/OM4 multimode 12-fiber cable
4 lanes, 10Gbit/s per lane.
Typical application: connect two switches or routers for high speed
interconnect
40GBase-SR4 max length:100m with OM3
Features
Cable Type: MTP Fan-Out Fiber Cable
Typical Application: To install directly into system equipment
ports or patch panel
Connector: MTP Female to 4 x LC Duplex
Fiber Count: 12, 8 used/4 not used
Specifications:
| Cable Type | MTP Fan-Out Fiber Cable |
| Typical Application | To install directly into system equipment ports or patch panel |
| Connector | MTP Female to 4 x LC Duplex |
| Fiber Count | 12, 8 used/4 not used |
| LC Jacket | 900um x 8 (4 pairs) |
| Cable Jacket | Aqua, 3.0mm |
| Fiber Category | OM3, 50/125 |
| Cable Length | 10ft (3m) |
| Data Rate | 40 Gigabit Ethernet 40GBase-SR4 |
Additional Information:
OFNP - Optical Fiber Nonconductive Plenum is the designation given
by the National Fire Protection Association (NFPA) to interior
Fiber optic cables which contain no electrically conductive
component, and which are certified for use in plenum applications.
