Universal Fixture Plate Fiber Optical Connector Polisher Machine
FOCC this kind of versatile polisher is designed for high quality
connector polishing. With the ability to polish up to 12 connectors
at once and control the polishing process on every level, the 550C
is the perfect solution to your polishing needs. It can consistent
and repeatable processes, also easily meets the industry level
standards for polishing including the specifications for TIA,
IEC/Bellcore, & GR326. Our polishing system let’s users tightly
control the radius, apex offset and fiber height.
Application
Re - Work;
R & D;
Low Volume Production.
Manufacturer | FOCC |
P / N | FOCC-550C |
Type | Pneumatically-Controlled Polishing Machine |
Polishing Capacity (max) | 24 Positions |
Pressure Source | Coil Spring |
Dimensions | 241 * 241 * 260mm |
Net Weight | 25 KGs |
Technical Data
O.D. of Rotation Plate | 127 mm(5 inch) |
Time Settings | 99 min 99 sec (Max) |
Speed for Rotation Plate | 15 - 200 rpm |
Height of Plate Jumpiness | <10 um |
Pressure Configuration: | 21 ~ 36 N/cm2 |
Work Temperature | 10 ~ 40 Celsius degrees / 10℃～40℃ |
Relative Humidity | 15%~85% |
Noise | unloading Less 50 dB |
Libration | Working Status 0.25g 5~100Hz 10min Stopping Status 0.50g 5~100Hz 10min |
Power Input | 220～230 VAC 50Hz / 60Hz |
Electric Power | 40 W |
Advantages
Polishing:
550C design utilizes the original polish methods which tightly
controls the radius, apex offset and fiber undercut.
Universal Fixture Plate:
Accommodates FC, SC, ST, FDDI, E2000PC, and 2.5mm Ferrules.
Versatility:
Easily accommodates a full range of industry standard polishing
styles: UPC, UPC, 8 DEG APC, 10 DEG APC, FLAT, SPHERICAL, RADIUS,
and DOMED. Polish a wide variety of ferrule material including:
ceramic, glass, stainless steel and plastic.
Shipping Method As Follow or Customized Requirements
FOCC Fiber Optical Connector Polishing Machine Quality
